Novel Measurement Technique for Fluid Mixing Phenomena Using Selective Color Imaging Method

image picture Image by Jamlong_cmi/Shutterstock

A novel measurement technique has been developed to visualize the fluid flow and distribution within two droplets levitated and coalesced in space using fluorescence-emitting particles. This technique enabled the estimation of fluid motion within each droplet, thereby revealing the internal flow caused by surface vibration when the droplet merging promotes fluid mixing.

Tsukuba, Japan—Generally, handling liquids requires containers. However, ultrasound technology can create a "lab-on-a-drop," an ultracompact testing environment, where multiple liquid droplets of several millimeters in diameter can float and mix in space, without the influence of a container. Researchers from the University of Tsukuba have developed a technique for merging two droplets, which are challenging to mix due to their small size in this lab-on-a-drop setup, and a method to measure their mixing using a selective color imaging method.

Herein, the mixing technique utilizes an ultrasonic phased array, which creates a focal point where droplets can float randomly via irradiating ultrasonic waves from a 7 × 7 grid of ultrasonic transducers with phase-shifting. This technique has successfully levitated two identical droplets simultaneously, leading them to collide and merge.

To measure the degree of mixing, it is essential to determine the flow of the fluid within each droplet. Here, the researchers utilized red and green fluorescent emitting particles; one droplet contained particles that fluoresce red under ultraviolet light irradiation, while the other contained particles that fluoresce green. As the droplets coalesced, the motion of each fluorescent particle was photographed in detail using a high-speed camera, thereby capturing their mixing state. Based on the time scale required for mixing, a comparative analysis of the difference between fluid mixing due to interfacial vibration during coalescence and due to molecular diffusion revealed that the mixing caused by interfacial vibration was predominant. Therefore, the findings of this research are promising for enhancing the application and further advancement of lab-on-a-drop devices.

Original Paper

Title of original paper:
Coalescence and mixing dynamics of droplets in acoustic levitation by selective colour imaging and measurement
Scientific Reports


Associate Professor KANEKO Akiko
Institute of Systems and Information Engineering, University of Tsukuba

Degree Program in Engineering Mechanics and Energy, Graduate School of Systems and Information Engineering, University of Tsukuba

Associate Professor HASEGAWA Koji
Department of Mechanical Engineering, Kogakuin University
